Operating Temperature
-
± -10 °C to ±85 °C (± -10 °F to ±179 °F)
Ingress Protection
-
IP65
Material
-
Polypropylene & Epoxy (Float), Polypropylene (Stem), PVC (Wire Jacket)
Stem Length
-
55 mm (2.17")
Float Height
-
21 mm (0.83")
Float Diameter
-
23 mm (0.91")
Pressure Limit
-
290 PSIG (20 bar)
Working Voltage
-
250 VAC, 200 VDC
Switching Current
-
0.5 A
Fitting
-
1/8" Male M10
- Designed to be mounted on the top or bottom of a tank
- Includes: Float, Stem, Washer, Nut
